ANXIYOU 500kVA / 400kW Diesel Generator Set

  • Information
  • Technical parameter

Product Overview

The 500kVA / 400kW diesel generator set is a reliable medium-to-large power solution designed for industrial, commercial, and infrastructure applications requiring stable and continuous electricity supply. It is suitable for both prime and standby power use.


Key Features

The unit is equipped with a high-performance diesel engine and advanced alternator system, ensuring stable voltage output, strong load capacity, and efficient fuel consumption. Its robust structure supports long-term continuous operation with high reliability.


Performance Advantages

Designed for demanding environments, the generator set delivers consistent performance under heavy loads and fluctuating conditions. It offers excellent durability, safety, and adaptability in high-temperature and harsh working environments.


Applications

Widely used in factories, commercial complexes, construction projects, mining operations, hospitals, and critical backup power systems, providing a stable and cost-effective power supply solution.

Product Specifications

Item

Value / القيمة

البند

Factory Model

AXY-500CMS

طراز المصنع

Genset Prime Power

500kVA / 400kW

القدرة الأساسية للمولد

Engine Brand

Cummins

علامة المحرك التجارية

Engine Model

QSZ13-G3

طراز المحرك

Engine Prime Power

562kVA / 450kW

القدرة الأساسية للمحرك

Engine Max Power

625kVA / 500kW

أقصى قدرة للمحرك

Rated Speed

1800RPM

السرعة المقدرة

Cylinder quantity

6

عدد الأسطوانات

Cylinder Arrangement

In-line

ترتيب الأسطوانات

Aspiration

Turbocharged & Air-to-Air Aftercooled (TAA)

نظام السحب

Bore x Stroke

130mm x 163mm

القطر × الشوط

Displacement

13.0L

الإزاحة

Compression Ratio

17:1

نسبة الضغط

Type Injection System

High Pressure Common Rail (XPI)

نوع نظام حقن الوقود

Speed Adjustment Method

Full Authority Electronic Control (ECU)

طريقة تنظيم السرعة

Total Lubrication System Capacity

45.4L

إجمالي سعة نظام التشحيم

Fuel Consumption at 50% load

54.8L/h

استهلاك الوقود عند حمل %50

Rated Voltage

400V / 230V

الجهد المقدر

Frequency

60HZ

التردد

Power Factor

0.8

معامل القدرة

Alternator Enclosure

IP23

درجة حماية المنوب

Phase

Three-Phase Four-Wire

الأطوار

Weight (approx.)

~7tons

الوزن تقريبًا

1. The above parameters are for reference only and cannot be used as any legal basis in the contract.

2. The manufacturer has the right to adjust or change the above parameters, and the data after adjustment or change will not be notified.
