Long Autonomy 25kVA / 20kW Diesel Generator with 1000L Fuel Tank

  • Information
  • Technical parameter

Extended Power, Unmatched Autonomy

Engineered for mission-critical reliability, this 25kVA diesel generator is designed specifically for remote locations and long-term backup scenarios. By integrating an industrial-grade 1000L oversized fuel tank, we have redefined "long autonomy," drastically reducing refueling frequency and operational downtime.

Key Features

  • Extreme Runtime: The high-capacity 1000L tank provides hundreds of hours of continuous operation at typical loads, making it the perfect "set-and-forget" solution for remote sites.

  • Industrial Precision: Powered by a high-efficiency diesel engine ensuring stable voltage output and superior transient response.

  • All-Weather Durability: Built with a heavy-duty, corrosion-resistant canopy designed to withstand harsh environments while maintaining low noise levels.

  • Smart Control: Equipped with a professional-grade digital controller for real-time monitoring of fuel levels, engine health, and power output.

  • Streamlined Maintenance: Thoughtfully designed access points for quick oil and filter changes, even in extended-run applications.

Ideal Applications

  • Telecommunication Base Stations

  • Off-grid Agricultural Facilities

  • Remote Construction Sites

  • Emergency Backup for Rural Infrastructure


Product Specifications


ltem

Value / القيمة

البند

Factory Model

AXY-20XC

طراز المصنع

Genset Prime Power

25KVA / 20KW

القدرة الساسية للمولد

Factory Date

2025-12-20

تاريخ التصنيع

Controller Pannel

SmartGen 6120N

لوحة التحكم

Engine Brand

FAWDE

علمة المحرك التجارية

Engine Model

4DW92-42D

طراز المحرك

Engine Prime Power

35KVA / 28KW

القدرة الساسية للمحرك

Engine Max Power

38.75KVA / 31KW

أقصى قدرة للمحرك

Rated Speed

1800RPM

السرعة المقدرة

Cylinder quantity

4

عدد السطوانات

Cylinder Arrangement

Vertical ln-line

ترتيب السطوانات

Aspiration

Naturally Aspirated

نظام السحب

Bore x Stroke

90mm x 100mm

القطر ×  الشوط

Displacement

2.54L

الزاحة

Compression Ratio

17:1

نسبة الضغط

Type lnjection System

Direct lnjection

نوع نظام حقن الوقود

Speed Adjustment Method

Mechanical Governor

طريقة تنظيم السرعة

Total Lubrication System Capacity

8L

إجمالي سعة نظام التشحيم

Fuel Consumption at 50% load

~4.1L/h

استهلك الوقود عند حمل 50%

Alternator Brand

LEROY-SMOER

علمة المنوب التجارية

Alternator Model

TAL-A42-CJ6S/4

طراز المنوب

Rated Voltage

400V / 230V

الجهد المقدر

Frequency

60HZ

التردد

Power Factor

0.8

معامل القدرة

Alternator Enclosure

lP23

درجة حماية المنوب

Circuit Breaker Brand

ABB

علمة قاطع الدورة

AMPS

32A

التيار أمبير

Phase

Three-Phase Four-Wire

الطوار

Fuel Tank

1000L

خزان الوقود

Dimensions

2150mm x 900mm x 2150mm

البعاد

Weight (approx.)

~1.5tons

الوزن تقريببا

1. The above parameters are for reference only and cannot be used as any legal basis in the contract.

2. The manufacturer has the right to adjust or change the above parameters, and the data after adjustment or change will not be notified.
