PP Plastic Film Faced Plywood
- Information
Product Overview
PP Plastic Film Faced Plywood is a high-performance construction formwork panel designed for concrete forming applications. The plywood surface is laminated with a durable polypropylene (PP) plastic film, providing excellent waterproof performance, smooth concrete finishing effect, and outstanding reusability.
Compared with traditional film faced plywood, PP plastic film faced plywood offers better wear resistance, moisture resistance, and longer service life. It is widely used in high-rise buildings, bridges, tunnels, industrial projects, and large-scale infrastructure construction.
The product combines strong core bonding strength with advanced surface protection technology, making it suitable for repeated use under harsh construction environments.
Product Features
Excellent Waterproof Performance
The PP plastic surface effectively prevents water penetration and protects the plywood core from moisture damage.
High Reusability
Compared with ordinary film faced plywood, the panel supports significantly more reuse cycles, reducing construction costs.
Smooth Concrete Surface
The plastic-coated surface produces smooth and clean concrete finishing with minimal surface defects.
Wear & Impact Resistance
The PP layer provides excellent abrasion resistance and impact durability for heavy-duty construction applications.
Strong Bonding Strength
Manufactured with high-quality hardwood or mixed hardwood core and strong adhesive bonding technology.
Easy Cleaning
Concrete residue can be cleaned easily after formwork removal, improving work efficiency.
Applications
High-Rise Building Construction
Bridge Engineering
Tunnel Construction
Industrial Projects
Infrastructure Construction
Concrete Formwork Systems
Wall & Slab Formwork
Column Formwork
Technical Specifications
| Item | Specification |
|---|---|
| Product Name | PP Plastic Film Faced Plywood |
| Core Material | Hardwood / Mixed Hardwood |
| Surface | PP Plastic Film |
| Thickness | 12mm / 15mm / 18mm / 21mm |
| Standard Size | 1220 × 2440 mm |
| Glue Type | Phenolic Glue / Melamine Glue |
| Density | 500–700 kg/m³ |
| Moisture Content | 8%–12% |
| Reuse Times | 30–50+ Times |
| Edge Sealing | Waterproof Paint Sealing |
| Surface Color | Green / Black / Brown |
| Application | Concrete Formwork |
Product Advantages
Longer Service Life
The PP plastic coating greatly improves panel durability and extends the working life of the plywood.
Reduced Construction Cost
Higher reuse frequency lowers material replacement costs and improves project efficiency.
Environmental Protection
Reusable structure reduces wood consumption and construction waste generation.
Stable Performance
Maintains stable strength and surface quality under humid and high-temperature environments.
