Automatic Transfer Switch Cabinet (ATS Panel)
- Information
Product Overview
The Automatic Transfer Switch Cabinet (ATS Panel) is an intelligent power switching system designed for automatic transfer between the main utility power source and backup diesel generator systems.
When the utility power fails or voltage becomes abnormal, the ATS panel automatically starts the generator and transfers the load to backup power. Once the utility power is restored, the system automatically switches the load back and shuts down the generator after cooling delay.
ATS panels are widely used in hospitals, data centers, industrial plants, commercial buildings, telecom stations, hotels, and emergency power systems where uninterrupted power supply is critical.
Product Features
Automatic Power Transfer
Automatically switches between utility and generator power without manual operation.
Fast Response Time
Ensures rapid load transfer during power failure, minimizing downtime and equipment interruption.
Intelligent Control System
Integrated microprocessor or PLC controller provides automatic monitoring and operation management.
Multiple Protection Functions
Equipped with over-voltage, under-voltage, overload, short circuit, and phase failure protection.
Stable & Reliable Operation
Industrial-grade electrical components ensure long-term stable performance in demanding environments.
Easy Maintenance
Modular cabinet structure simplifies inspection, maintenance, and component replacement.
Applications
Diesel Generator Systems
Hospitals & Medical Facilities
Data Centers
Industrial Factories
Commercial Buildings
Telecom Base Stations
Hotels & Shopping Centers
Emergency Backup Power Systems
Technical Specifications
| Item | Specification |
|---|---|
| Product Name | Automatic Transfer Switch Cabinet |
| Rated Current | 63A – 3200A |
| Rated Voltage | 220V / 380V / 400V / 415V |
| Frequency | 50Hz / 60Hz |
| Phase | 3 Phase / Single Phase Optional |
| Switching Mode | Automatic / Manual |
| Controller Type | PLC / Microprocessor Controller |
| Transfer Time | ≤10 Seconds |
| Protection Functions | Overload / Short Circuit / Phase Failure |
| Cabinet Material | Powder Coated Steel |
| Protection Level | IP42 / IP54 / IP55 |
| Installation Type | Indoor / Outdoor Optional |
Key Functions
Utility Power Monitoring
Automatic Generator Start/Stop
Automatic Power Transfer
Emergency Backup Switching
Real-time Status Monitoring
Fault Alarm & Protection
Optional Configurations
Deep Sea Controller
ComAp Intelligent Controller
Touch Screen HMI
Remote Monitoring System
SCADA Communication
Weatherproof Outdoor Cabinet
Dual Power Input System
Busbar Upgrade Solution
Product Advantages
Uninterrupted Power Supply
Automatically restores backup power during utility failure to protect critical equipment.
Intelligent Automation
Reduces manual operation and improves overall power management efficiency.
High Compatibility
Compatible with most diesel generators and utility power systems.
Industrial-Grade Reliability
Suitable for continuous operation in industrial and high-temperature environments.
