T series
"T" series is our traditional lighting lighthouse, equipped with 4 lamps, easy to operate, economical and practical.
- Information
- Technical parameter
"T" series is our traditional lighting lighthouse, equipped with 4 lamps, easy to operate, economical and practical.
| Product Model | 4TN6000 | 4TN1200 | |||
| Overall dimensions | L | 4360mm (14'4”) | |||
| W | 1430 mm(4'8") | ||||
| H | 1450mm (4'9") | ||||
| Working height | 9m (29'6”) | ||||
| Weight | 980kg (2160lb) | 910kg (20101b) | |||
| Engines | Model number | D1105(Kubota) | Z482(Kubota) | ||
| Number of revolutions per minute | 1500/1800 | 3000/3600 | |||
| Number of cylinders | 3 | 2 | |||
| Emission class | eligible | ||||
| Electricity generator | Model number | SPARKS | |||
| Poles and Luminaires | Lamp type | Flooded Full Halogen Lamps | LED light | ||
| Lamp structure | elliptical | rectangles | |||
| Lamp Lumens（LM） | 165000 LM/ight | 390000 LM/light | |||
| Wattage and number of lamps | 4x1500W | 4x3000W | |||
| Number of light pole sections | 3 | ||||
| Light pole lifting method | Manually operated | ||||
| Lamp Pole Rotation Method | Manually operated | ||||
| Lamp Angle Adjustment | Manual, maximum rotation 330° lockable | ||||
| Trailer frame | Trailer Suspension & Brakes | Leaf Spring County Hitch & Brake-less Single Wheel Axle | |||
| Tow bar | Telescopic adjustable guide wheel tow bar | ||||
| Legs and potency | 4 sets of hand-operated support legs with telescopic jacks | ||||
| Rim and Tire Size | 14 inch, regular tires | ||||
| Traction head type | 2" or 50 mm ball retractor | ||||
| Tail light | Reflector | ||||
| Maximum traction speed | 100km/h (62 mph) | ||||
| Other features | Fuel tank type | Rotomolded plastic fuel tanks | |||
| Fuel tank capacity | 170 liters (45 gallons) | ||||
| Distance travel time with all lights on | 80H | 360H | |||
| Wires & Electrical Components | Ordinary | ||||
| Type of unit startup/control | Key activation | ||||
| Maximum wind resistance at full extension | 20m/s(45mph) | ||||
| Noise reduction rating | Noise level 72dB(A) at 7 meters | ||||
| Standard colors | SWT Orange or yellow housing, black chassis, galvanized pole, tow bar & support legs | ||||
| Maximum number of 40' tall cabinets that can be loaded | 12or14 | ||||
1. The above parameters are for reference only and cannot be used as any legal basis in the contract.
2. The manufacturer has the right to adjust or change the above parameters, and the data after adjustment or change will not be notified.
1. The above parameters are for reference only and cannot be used as any legal basis in the contract.
2. The manufacturer has the right to adjust or change the above parameters, and the data after adjustment or change will not be notified.
